EBIS Integrated photo inspection machine
Can Be Translated As "Introduction To Comprehensive Cracked Bottle Inspection Machine".
It is a device used for detecting cracks on bottles, which can quickly and efficiently detect cracks on the
surface and inside of bottles to ensure product quality and safety.
The machine usually comes equipped
with multiple cameras, light sources, and sensors, and can automatically inspect and classify bottles while
also collecting and analyzing data.
It is widely used in industries such as pharmaceuticals, food, and cosmetics, and is essential for ensuring product quality and production efficiency.
1、The model of the integrated photo inspection machine is SLSF-M-270/330.
2、Power supply requirements for the integrated photo inspection machine: Input power AC380V AC power supply + N + dedicated ground wire, power 5KW.
3、Product inspection diameter range: 20-102mm (Specify if equipment size is non-standard when ordering).
4、Product inspection height range: 40-360mm (Specify if equipment size is non-standard when ordering).
5、This system has 12 testing stations with a normal operating speed of less than 250 units/minute and a maximum speed of 250 units/minute. The servo comprehensive station can use a 270-plate or a 330-plate and accommodate 6 stations for large diameter bottles, a 12-station star wheel plate for medium diameter products, or a 24-station plate for small diameter products(Specify if equipment size is non-standard when ordering).
6、Material colors for inspection: transparent, green, and brown bottles.
※We can customize the size of testing products according to customer needs
